The Covidien Kendall SCD 700 Series is a sequential compression system designed to improve circulation and reduce swelling in patients. It is widely used in medical settings.
Overview of the Device and Its Purpose
The Covidien Kendall SCD 700 Series is a sequential compression system designed to enhance blood circulation and reduce swelling in limbs. It is primarily used in medical settings to prevent deep vein thrombosis (DVT) and promote patient mobility. The device delivers intermittent pneumatic compression through sleeves wrapped around the legs‚ ensuring a safe and effective therapy session. Its compact design and user-friendly interface make it ideal for both clinical and home care environments‚ offering reliable performance for optimal patient outcomes.
Error Types and Troubleshooting
The Covidien Kendall SCD 700 Series features three error categories: User Resettable‚ Manual Reset Required‚ and Service Required. Each type has specific causes and solutions.
User Resettable Errors
User Resettable Errors on the Covidien Kendall SCD 700 Series are issues that can be resolved by the operator without technician assistance. Examples include incorrect sleeve connections or low battery levels. These errors are indicated by specific alarm codes and messages on the device’s display. Users can address them by following on-screen instructions‚ such as reconnecting sleeves properly or charging the device. This feature empowers users to quickly restore functionality‚ minimizing downtime during therapy sessions.
Manual Reset Required Errors
Manual Reset Required Errors on the Covidien Kendall SCD 700 Series occur when the system detects issues needing operator intervention beyond basic troubleshooting. These errors‚ such as system overload or communication failures‚ require the user to manually reset the device. The manual reset process typically involves turning the device off and on or pressing specific buttons as indicated in the user manual. These errors ensure patient safety by prompting immediate action to restore proper functionality. Always refer to the manual for detailed reset instructions.
Service Required Errors
Service Required Errors on the Covidien Kendall SCD 700 Series indicate critical issues that cannot be resolved by the user and require professional attention. These errors typically involve internal system malfunctions‚ such as component failures or software issues. The device will alert users with specific error codes‚ and operation must cease until the issue is addressed. Contacting Covidien’s authorized service center is essential for repair. Always ensure the device is powered down before servicing to avoid further damage or safety risks.
Operation Manual Details
The Covidien Kendall SCD 700 Series manual provides detailed instructions for setting up‚ initiating therapy‚ and adjusting compression settings. It ensures safe and effective operation.
Setting Up the Device
Setting up the Covidien Kendall SCD 700 Series involves inspecting the power cord for damage‚ ensuring proper connection of tubing to both the system and sleeves‚ and verifying snug fit of sleeves on the patient. The system must be placed on a stable surface‚ and all components should be checked for integrity. Proper setup ensures safe and effective therapy‚ adhering to Covidien’s guidelines for optimal patient outcomes and device performance.
Starting the Therapy Session
To start therapy‚ ensure the device is powered on and all connections are secure. Verify the sleeves are properly fitted and secured to the patient. Navigate to the therapy mode using the controller‚ select the appropriate compression settings‚ and confirm the start command. The system will initiate a self-check to ensure all components are functioning correctly. Therapy begins once the system confirms all settings and connections are valid‚ providing intermittent compression to enhance circulation.
Adjusting Compression Settings
Compression settings can be adjusted using the controller’s interface. Use the arrow keys to select desired pressure levels‚ cycle times‚ and inflation/deflation rates. Ensure settings align with patient comfort and therapeutic goals. The system allows customization to optimize circulation without causing discomfort. Always refer to guidelines for proper adjustment to ensure effectiveness and safety during therapy sessions. Properly secured sleeves and accurate settings are crucial for optimal results.
Safety Precautions and Maintenance
Inspect the power cord for damage before use. Charge only with Covidien-specified chargers. Regularly clean and maintain components to ensure optimal performance and patient safety.
Inspecting the Power Cord and Components
Regularly inspect the power cord for signs of wear‚ such as fraying or damage. Ensure all components‚ including connectors and tubing‚ are free from visible damage. If damage is detected‚ immediately stop use and contact Covidien’s service center for repair. Proper inspection ensures safe operation and prevents potential hazards. Always follow Covidien’s guidelines for maintenance to maintain device functionality and patient safety.
Proper Charging Procedures
Charge the Kendall SCD 700 Series only with Covidien-approved chargers to ensure safety and optimal performance. Avoid using unauthorized chargers‚ as they may damage the device. Plug the charger into a grounded outlet and connect it to the controller until fully charged. Charging indicators will signal when the process is complete. Always follow Covidien’s instructions for charging to maintain battery life and system reliability.
Compression Garments and Application
Ensure a snug fit for compression garments‚ allowing space for two fingers between the sleeve and leg. Secure cuffs tightly‚ similar to a sneaker fit.
Guidelines for Proper Fit
Ensure compression garments fit snugly‚ allowing space for two fingers between the sleeve and leg. Sleeves should be wrapped smoothly‚ avoiding wrinkles or twists. Secure cuffs tightly‚ similar to a sneaker fit‚ to maintain consistent pressure. Proper fit ensures effective therapy and patient comfort. Always follow the manufacturer’s sizing chart for accurate fit. Improper fit may lead to reduced efficacy or discomfort.
Securing the Sleeves Correctly
To secure sleeves correctly‚ wrap them snugly around the limb‚ ensuring they lie flat without overlapping. Fasten the cuffs firmly but not overly tight‚ using the provided straps or clips. Make sure the connection points align properly and there are no twists or kinks in the tubing. This ensures even pressure distribution and effective therapy. Regularly check the sleeve alignment and tightness to maintain optimal performance throughout the session.
Vascular Refill Detection Technology
The Covidien Kendall SCD 700 Series features Vascular Refill Detection Technology‚ which monitors and adjusts compression based on patient-specific blood flow patterns for optimal therapy outcomes.
How the Technology Works
The Vascular Refill Detection Technology in the Covidien Kendall SCD 700 Series uses sensors to monitor limb resistance and blood flow patterns. It continuously adjusts compression levels to ensure optimal therapy delivery‚ customizing the treatment based on real-time physiological data. This advanced system detects when blood vessels refill and adapts the compression cycle to enhance circulation effectively. The technology ensures that therapy is both safe and tailored to individual patient needs‚ improving overall treatment outcomes.
Benefits for Patient Therapy
The Covidien Kendall SCD 700 Series enhances patient therapy by improving circulation‚ reducing swelling‚ and promoting healing. Its advanced Vascular Refill Detection Technology customizes therapy to individual needs‚ ensuring optimal results. Patients experience enhanced mobility and comfort during sessions. The system is non-invasive‚ safe‚ and effective‚ making it a trusted solution for improving vascular health. Regular use can prevent complications and accelerate recovery‚ providing a reliable and patient-friendly treatment option for managing circulatory conditions.
Service and Repair Information
Contact Covidien’s authorized service center for repairs. Trained technicians ensure compliance with safety guidelines. Regular maintenance extends device lifespan and ensures optimal performance.
Contacting Covidien Service Center
To ensure proper repair and maintenance‚ contact Covidien’s authorized service center. Trained technicians handle repairs efficiently‚ adhering to safety guidelines. For controller issues‚ ship the device with a detailed description of the problem. Include contact information and a return shipping address. Technicians will diagnose and repair faults promptly. Regular servicing by Covidien ensures optimal performance and longevity of the SCD 700 Series. Always use authorized services to maintain warranty validity and device reliability.
Relevant Service Manual References
Refer to Section IV of the Kendall SCD 700 Series manual for detailed fault conditions and troubleshooting steps. Attachment A provides specific repair procedures for damaged power cords. Page 16 outlines proper charging guidelines‚ while Section EN-13 covers service-related instructions. The manual also includes references for contacting Covidien’s service center and understanding the operating principles of the system. Ensure to follow all outlined procedures to maintain device performance and safety. Always refer to the official Covidien service manual for accurate and comprehensive guidance.
